AP Valves Evolution Vision Rebreather
View the Rebreather Comparison page for the features and specs of the
Evolution and Evolution+Vision CCRs
FOR FULL DETAILS OF THE VISION ELECTRONICS CLICK HERE
OR TAKE A LOOK AT THE SIMULATOR BELOW
|
THE EVOLUTION +
With the Inspiration offering advantages in scrubber duration and the Evolution offering advantages in size and weight, the choice between the two has proved a tough one for some customers. We are delighted to introduce our hybrid unit...the Evolution+.
The Evolution+ combines the 2 litre cylinders from the Evolution and the larger scrubber as used on the Inspiration, all housed in a new specially designed case giving the best of both worlds.
The Evolution+ is available now.
|
| AUTOMATIC DILUENT VALVE (ADV) |
 |
SAVE MONEY NOW
BUY THE ADV WITH YOUR INSPIRATION CLASSIC TODAY & SAVE £33.50
|
|
Fitted in place of the inhale T-piece - the ADV supplies gas to the breathing circuit whenever a substantial negative pressure is experienced within the inhale counterlung or when manually operated by pressing the diaphragm cover.
The gas supply hose connects with a 3/8" UNF thread to the low pressure port (7 to 11 bar) of a first stage or into the diluent port of the INSPIRATION or EVOLUTION manifold. At the other end it connects to the ADV's 300 degree swivel with a standard 9/16" UNF female regulator connector.
The ADV valve is an upstream tilt valve that requires no adjustment or free-flow cut-off device.
The 300 degree swivel gives you the option of feeding the hose from the front e.g. from a suitable side-mounted diluent cylinder.
The ADV is not a pressure relief valve like a normal downstream 2nd stage. It is an upstream design which prevents free-flow into the breathing circuit in the event of a leaking 1st stage seat.
The ADV comes with a C Spanner and an ADV Hose - either an AP300/10 10" Evolution hose or an AP300/15 15" Inspiration hose.
|
| FLOWSTOP |
.jpg) |
The Flow-Stop is an in-line gas isolator. Simply slide the black knurled collar forwards in the direction of the gas flow to instantly cut off the gas supply. |
SAVE MONEY NOW
BUY THE ADV & FLOWSTOP
WITH YOUR INSPIRATION CLASSIC TODAY
|
| OPEN CIRCUIT BAILOUT MOUTHPIECE (OCB) |
| The OCB enables the diver to bail out to open circuit easily, with one movement, without removing the mouthpiece from their mouth. |
 |
| SCRUBBER MONITOR TEMP STICK |
 |
Scrubber monitor for the Inspiration Vision Electronics.
Just plugs into the head and replaces scrubber column.
|
There are 3 sizes of Counterlungs, Medium, Large, XLarge.
To measure: wearing trousers with a belt and a T-Shirt, measure from the lower edge of the belt at the front,
over your shoulder and down to the belt at the back. Take the measurement on inhale:-
Under 110cms - Medium Counterlungs
Over 110cms - Large Counterlungs
Over 125cms - XLarge Counterlungs |
If you would like to order this rebreather download and fill out this form, then just save and send to us as an attachment to sales@diverswarehouse.co.uk or alternatively fax to 0044 (0) 1274 307555
Evolution Rebreather
- Vision Upgrades Scrubber Monitor
- Software Nitrox & Trimix Software
- Wing Size STD 16kg
- Lung Size Medium-Large-Extra Large
- Lung Colour Black/Yellow-Gray
- Accessories ADV & Flowstop
- Harness Size Medium-Large-Extra Large
|
